RGBS to VGA Solutions

1. Introduction

Convert non-generic RGBS (RGB & composite sync) signals to VGA signals that can be recognized by generic monitor, which is simple、use commonly in system and low cost

2. Applications

Arcade Games display

Bowling alley display system

VMIC display

3. Specification

Input：

YPbPr （480i,576i,480p,576p,720p,1080i,1080p）

VGA BYPASS output

RGBS： CGA/EGA，15K、24K、31K

Output：

VGA resolution (640X480-1920X1200)

4. Function & Features

Support SOURCE switch、OSD display、Brightness/Contrast adjustment

Support auto adjustment of nonstandard signal and high compatibility

The board is simple and easy to produce
