HDMI/YPbPr/VGA to AV Solutions

1. Introduction：

This product supports HDMI/YPbPr/VGA input and analog video output. Using digitizing processing to convert high-resolution HD analog digital signal and Audio (L/R) stereo signals to analog video signal output

2．Applications

Professional camera equipment output signal format’s conversion

Broadcast & television projects

Video signal capture

3. Specification

input port: HDMI,YPbPr,VGA

output port: AV

HDMI(DVI) input mode:

480i,576i,480p,576p,720p(50Hz/60Hz),1080i(50Hz/60Hz), ,
1080p(50Hz/60Hz),800x600@60Hz,1024x768@60Hz,
1280x1024@60Hz,1600x1200@60Hz；

YPbPr input mode：

480i,576i,480p,576p,720p(50Hz/60Hz),1080i(50Hz/60Hz),1080p(50Hz/60Hz)

VGA input mode:

00x600@60Hz,1024x768@60Hz,1280x1024@60Hz,1600x1200@60Hz；

AV output mode: PAL/ NTSC3.58

4. Function & Features

It can convert HDMI/DVI/YPbPr/VGA signal to AV(CVBS) composite video signal and FL/FR stereo signals with advanced design、originality、expand and auxiliary function.

Signal processing adopts horizontal and vertical data interpolated technology、3D motion compensation、dynamic noise reduction and smoothing algorithm etc., which is lossless but with compensation function to make output images more stable、natural and good color rendition.

Low consumption、attractive appearance、small and exquisite

Reliable upgrade features let customers convert full HD HDMI signals、YPbPr signals and VGA output signals from PC to CVBS signals (standard resolution PAL,NTSC) which can be received by TV、VHS player and DVD.
